Push In Connection

Push In Connection manufacturer in India

Push In Connection

Reliable, Fast & Tool-Free Wiring Solutions

Elmex Push In Connection Terminal Blocks are designed to simplify electrical wiring while ensuring secure and reliable connections. With advanced push-in technology, conductors can be inserted directly into the terminal without the need for special tools, significantly reducing installation time and improving efficiency in industrial control panels, switchgear systems, and automation applications.

Built for high-performance electrical connectivity, these terminal blocks provide excellent vibration resistance, long-term contact reliability, and consistent electrical performance in demanding environments.

Push In Connection Manufacturer and Supplier in India – Elmex

Products

PQT2.5

CE Mark Conforming to IEC Specification
  • IEC : 500 V / 15 A / 2.5 sq.mm / NAV Nm
  • Thickness : 7.5 mm / 0.3 inches
  • Width : 19 mm / 0.75 inches
  • Height : 23.7 mm / 0.93 inches

PGQ1.5

CE Mark Conforming to IEC Specification
  • IEC : 1.5 sq.mm
  • Thickness : 3.5 mm / 0.14 inches
  • Width : 47.56 mm / 1.87 inches
  • Height : 30.7 mm / 1.21 inches

PQ2.5-2T

CE mark for explosion-proof Approval as per ATEX directive UL Recognition for USA CE Mark Conforming to IEC Specification IEC CB LR :  Lloyd’s Register IEX Ex
  • IEC : 1000 V / 24 A / 2.5 sq.mm
  • Thickness : 5 mm / 0.2 inches
  • Width : 73.2 mm / 2.88 inches
  • Height : 47 mm / 1.85 inches

PQK2.5

CE mark for explosion-proof Approval as per ATEX directive UL Recognition for USA CE Mark Conforming to IEC Specification IEC CB LR :  Lloyd’s Register IEX Ex
  • IEC : 1000 V / 20 A / 2.5 sq.mm
  • Thickness : 5 mm / 0.2 inches
  • Width : 62.81 mm / 2.47 inches
  • Height : 40 mm / 1.57 inches

PQF4

UL Recognition for USA CE Mark Conforming to IEC Specification IEC CB LR :  Lloyd’s Register
  • IEC : 1000 V / 6.3 A / 4 sq.mm
  • Thickness : 6 mm / 0.24 inches
  • Width : 56.2 mm / 2.21 inches
  • Height : 61.1 mm / 2.41 inches

PQ4+D

CE Mark Conforming to IEC Specification
  • IEC : 1000 V / 1 A / 4 sq.mm
  • Thickness : 6 mm / 0.24 inches
  • Width : 56.2 mm / 2.21 inches
  • Height : 36 mm / 1.42 inches

PQ2.5-1X2

CE mark for explosion-proof Approval as per ATEX directive UL Recognition for USA CE Mark Conforming to IEC Specification IEC CB LR :  Lloyd’s Register IEX Ex
  • IEC : 1000 V / 24 A / 2.5 sq.mm
  • Thickness : 5 mm / 0.2 inches
  • Width : 62.7 mm / 2.47 inches
  • Height : 36 mm / 1.42 inches

PQ1.5

CE mark for explosion-proof Approval as per ATEX directive UL Recognition for USA CE Mark Conforming to IEC Specification IEC CB LR :  Lloyd’s Register IEX Ex
  • IEC : 1000 V / 17.5 A / 1.5 sq.mm
  • Thickness : 3.5 mm / 0.14 inches
  • Width : 47.2 mm / 1.86 inches
  • Height : 30.5 mm / 1.2 inches
