Feed Through Terminal Blocks

Feed Through Terminal Blocks Manufacturer in India

Feed Through Terminal Blocks

'elmex' feed-through terminal blocks are electrical connectors used to securely pass current through a system while organizing wires. They typically have two aligned connection points (input and output) and with spring clamp connections technology. Mounted on DIN rails or panels, they save space, are often color-coded for easy identification, and are used in control panels, distribution boxes, and industrial automation. To use them, select the correct type.

Feed Through Terminal Blocks Manufacturer and Supplier in India – Elmex

Products

SQ2.5

CE mark for explosion-proof Approval as per ATEX directive UL Recognition for USA CE Mark Conforming to IEC Specification IEC CB LR :  Lloyd’s Register IEX Ex
  • IEC : 1000 V / 24 A / 2.5 sq.mm
  • Thickness : 5 mm / 0.2 inches
  • Width : 50.7 mm / 2 inches
  • Height : 36 mm / 1.42 inches

SQ4

CE mark for explosion-proof Approval as per ATEX directive UL Recognition for USA CE Mark Conforming to IEC Specification IEC CB LR :  Lloyd’s Register IEX Ex
  • IEC : 1000 V / 32 A / 4 sq.mm
  • Thickness : 6 mm / 0.24 inches
  • Width : 56 mm / 2.2 inches
  • Height : 36 mm / 1.42 inches

SQ6

CE mark for explosion-proof Approval as per ATEX directive UL Recognition for USA CE Mark Conforming to IEC Specification IEC CB LR :  Lloyd’s Register IEX Ex
  • IEC : 1000 V / 41 A / 6 sq.mm
  • Thickness : 8 mm / 0.31 inches
  • Width : 64.2 mm / 2.53 inches
  • Height : 43 mm / 1.69 inches

SQ10

CE mark for explosion-proof Approval as per ATEX directive UL Recognition for USA CE Mark Conforming to IEC Specification IEC CB LR :  Lloyd’s Register IEX Ex
  • IEC : 1000 V / 57 A / 10 sq.mm
  • Thickness : 10 mm / 0.39 inches
  • Width : 73.7 mm / 2.9 inches
  • Height : 48 mm / 1.89 inches

SQ16

CE mark for explosion-proof Approval as per ATEX directive UL Recognition for USA CE Mark Conforming to IEC Specification IEC CB LR :  Lloyd’s Register IEX Ex
  • IEC : 1000 V / 76 A / 16 sq.mm
  • Thickness : 12 mm / 0.47 inches
  • Width : 83.2 mm / 3.28 inches
  • Height : 50.5 mm / 1.99 inches
