Name: Multi Level Terminal Blocks
Brand: Elmex
Rating: 5 (5 reviews)

Multi Level Terminal Blocks

'elmex' multilevel terminal blocks offer multiple connection levels in one housing, saving space and organizing complex wiring. They are used in control panels and automation systems, and come with screw clamp connections technology.

Products

TQ2.5-2T

CE mark for explosion-proof Approval as per ATEX directive

IEC : 500 V / 24 A / 2.5 sq.mm / 0.4 Nm
Thickness : 5 mm / 0.2 inches
Width : 70.6 mm / 2.78 inches
Height : 62.5 mm / 2.46 inches

TQ2.5-2T+IS

IEC : 500 V / 24 A / 2.5 sq.mm / 0.4 Nm
Thickness : 5 mm / 0.2 inches
Width : 70 mm / 2.76 inches
Height : 62.5 mm / 2.46 inches

TQ2.5-2T+E

IEC : 400 V / 24 A / 2.5 sq.mm / 0.4 Nm
Thickness : 6 mm / 0.24 inches
Width : 76.1 mm / 3 inches
Height : 56 mm / 2.2 inches

TQ2.5-2T+WOE

IEC : 400 V / 24 A / 2.5 sq.mm / 0.4 Nm
Thickness : 6 mm / 0.24 inches
Width : 76.1 mm / 3 inches
Height : 56 mm / 2.2 inches

TQ4-2T

IEC : 500 V / 32 A / 4 sq.mm / 0.5 Nm
Thickness : 6 mm / 0.24 inches
Width : 70.6 mm / 2.78 inches
Height : 62.5 mm / 2.46 inches

TQ2.5-3T

IEC : 1000 V / 24 A / 2.5 sq.mm / 0.4 Nm
Thickness : 6 mm / 0.24 inches
Width : 90 mm / 3.54 inches
Height : 70 mm / 2.76 inches

TQ2.5-3T+E

IEC : 400 V / 24 A / 2.5 sq.mm / 0.4 Nm
Thickness : 6 mm / 0.24 inches
Width : 94.6 mm / 3.72 inches
Height : 71.5 mm / 2.81 inches

TQ2.5-3T+WOE

IEC : 400 V / 24 A / 2.5 sq.mm / 0.4 Nm
Thickness : 6 mm / 0.24 inches
Width : 94.6 mm / 3.72 inches
Height : 71.5 mm / 2.81 inches
